Name: Setra’s Model 267 Very Low Differential Pressure Transducer
SKU: Setra 267 Series
Price: 2160.00 AUD
Availability: InStock

Setra’s Model 267 Very Low Differential Pressure Transducer

$2,160.00

Setra’s Model 267 is the most rugged high accuracy, low differential pressure transducer on the market.

It delivers accuracies of ±1% FS (without display), ±0.5% FS (with display), and optional ±0.25% FS and ±0.4% FS accuracies, and pressure ranges from 0.1” W.C. up to 100” W.C.
The 267 is housed in a robust, NEMA 4 rated enclosure and has an optional static pressure probe reducing installation and material costs.

The 267 is offered with an optional LCD display and a standard accuracy of ±0.5% making it ideal for high accuracy Pharmaceutical applications.

Product Enquiry Form

First Name

Last Name

Company Name

Address

Address Line 1

Address Line 2

City

State

Post Code

Country

Phone/Mobile

How many units are you wanting to purchase?

How can we help?

Check Stock Avail & Delivery

Request Quote by email

Request WhatsApp text message

Check if alternative available

Your Message

Upload photo or file to help

Choose File

Setra’s Model 267 pressure transducer sense gauge (static) or differential pressure in air pressure ranges as low as 0.1”WC Full Scale up to 100”WC. The Model 267 gauge pressure transducer is offered in a high level voltage or 4 to 20 mA output and is available with a static pressure probe for installation directly onto the duct. The 0.25” diameter pressure probe is made of sturdy extruded aluminum and is designed with baffles to prevent velocity pressure errors. This unit is also available with an LCD display. The 267MR multi-range transducer offers 6 field selectable pressure ranges (bidirectional and unidirectional), and field configurable outputs of 0 to 5 VDC, 0 to 10 VDC, and 4 to 20 mA. With the flip of a switch the user can field calibrate the unit and be assured of optimum performance.

• Optional 3.5 Digit LCD Display w/ 0.5% FS Accuracy
• NEMA 4 Rated Housing
• Optional Static Pressure Probe
• PG-9, PG-13 or Conduit Electrical Termination
• 24 VAC or 24 VDC Excitation
• CE & RoHS Compliant
• Suitable for Harsh Environments
• Optional LCD Display
• ±0.25%, 0.4%, 0.5%, 1% FS Accuracy
