Johnson Controls offers a Carbon Dioxide (CO2) and temperature
wall mount transmitter for measuring the CO2 levels and the
relevant temperature. Optional with humidity measurement.
Typical applications are schools, office buildings, hotels, cinemas
or similar. This new CO2 transmitter is easy to install and requires
no maintenance or field calibration
- Power supply active 0..10V 15..35 V = or 19..29 V ~ SELV
- Power consumption max. 0,4 W (24 V =) | 0,8 VA (24 V ~)
- Measuring range temp. 0..+50 °C
- Measuring range CO2 0..2000 ppm
- Measuring range humidity 0..100 % rH
- Analogue output 2x/3x 0..10 V, min. load 10 kΩ
- Accuracy temperature ±0,5K (typ. at 21 °C)
- Accuracy CO2 ±50 ppm +3% of measured value (typ. @ 21 °C, 50% rH)
- Accuracy humidity ±2% between 10..90% rH (typ. at 21 °C)
- Calibration self-calibration, Dual Channel
- Sensor NDIR (non-dispersive, infrared)
- Enclosure PC V0, pure white
- Protection IP20 according to EN 60529
- Cable entry rear entry, breaking points, drill mark top
- Connection electrical tool-free mountable spring terminal, max. 1,5 mm²
- Ambient condition 0..+50 °C, max. 85% rH, non-condensing
- Storage condition -30..+70 °C, max. 85% rH, non-condensing
