FX-PCV1930-0

VAV Cntrl/IP 3UI +3BO+2CO, SA bus for NS sensor

The FX-PCV1930 programmable digital controllers are designed for Variable Air Volume (VAV) applications that communicate over BACnet®/IP networks. These FX-PCV controllers feature combinations of an integral digital pressure sensor (DPT), a damper actuator, and a 32-bit microprocessor. The controllers’ small package size facilitates quick field installation and efficient use of space without compromising high-tech control performance. The FX-PCV1930 controllers include an integral real-time clock, which enables the controllers to monitor and control schedules, calendars, and trends, and operate for extended periods of time as stand-alone controllers when offline from the Facility Explorer® system network. These FX-PCV controllers connect easily to the wired and wireless network sensors for zone and discharge air temperature sensing.

The Facility Explorer system controllers and network sensors communicate using the BACnet protocol. The BACnet protocol is a standard for ANSI, ASHRAE, and the International Standards Organization (ISO) for building controls. FX-PCV1930 Controllers are BACnet Testing Laboratories (BTL) listed and certified BACnet Advanced Application Controllers (B-AACs).
